Cutaway Isometric view of Tottenham Court Road Station showing the new Ticket Hall and Elizabeth line platforms. The purpose of the drawing was to illustrate the speed of access between the Rathbone Square development and platform level. The client was unable to supply any reference material so all information had to come from the public domain.
